JH Series Catalogue

New Composite Catalogue

A complete view of CNC solutions built for performance, productivity, and reliability.

Smart Series Catalogue

Turning Length: 200 mm to 370 mm Turning Diameter: 150 mm to 320 mm Chuck Diameter: 5” to 8” Power: up to 7.5/5.5 Kw

S Turn Catalogue

Turning Length: 300 mm Turning Diameter: 320 mm Chuck Diameter: 8” Power: up to 7.5/5.5 kW

LX Series Catalogue

Turning Length: 310 mm to 687 mm Turning Diameter: 320 mm Chuck Diameter: 8” Power: up to 11/7.5 kW

LL 20 Series Catalogue

Turning Length: 310 mm to 1040 mm Turning Diameter: 320 mm to 400 mm Chuck Diameter: 8” to 12” Power: up to 18.5/15 kW

LL 30 Series Catalogue

Turning Length: 310 mm to 1040 mm Turning Diameter: 320 mm to 400 mm Chuck Diameter: 8” to 12” Power: up to 18.5/15 kW

LR Series Catalogue

Turning Length: 400 mm to 3000 mm Turning Diameter: 470 mm to 600 mm Chuck Diameter: 12” to 16” Power: up to 22/18.5 kW

LF Series Catalogue

Turning Length: 310 mm to 1040 mm Turning Diameter: 320 mm to 400 mm Chuck Diameter: 8” to 12” Power: up to 18.5/15 kW

LTV Series Catalogue

Turning Length: 500 mm to 800 mm Turning Diameter: 500 mm to 800 mm Chuck Diameter: 12” to 20” Power: up to 22/18.5 kW

JD Series Catalogue

X Axis: 500 mm to 700 mm Y Axis: 400 mm Z Axis: 320mm to 450mm Power: up to 26/11/4.5 Spindle Speed: up to 24000 rpm

JZ Series Catalogue

J Series Catalogue

X Axis: 600 mm to 1000 mm Y Axis: 500 mm to 600 mm Z Axis: 500mm to 600mm Power: up to 18.5/15 Spindle Speed: up to 8000 rpm

JV Series Catalogue

X Axis: 575 mm to 2000 mm Y Axis: 410 mm to 900 mm Z Axis: 460mm to 800mm Power: up to 18.5/15 Spindle Speed: up to 8000 rpm

JH Series Catalogue

X Axis: 600 mm to 800 mm Y Axis: 600 mm to 800 mm Z Axis: 640mm to 850mm Power: up to 37/30/22 Spindle Speed: up to 12000 rpm
