JH 400
JH 400 is a Horizontal Machining Center designed for demanding machining applications and consistent production performance. With axis strokes of 600 × 600 × 640 mm and a 400 × 500 mm pallet, it offers stable and precise machining for a wide range of components. Available with a Rotary Automatic Pallet Changer, it enables improved productivity and reduced setup time. It is well-suited for Pump & Valve, Automobile, Oil & Gas, Agriculture, and Defence industries.
Specifications
Description
Unit
Type
X/Y/Z Axis
mm
600 x 600 x 640 mm600 x 600 x 640
Max. Work piece diameter
mm
630 mm630
Max. Work piece length
mm
700 mm700
Pallet size
mm
400 x 500 mm400 x 500
No of Pallets
nos.
2 nos.2
Maximum load on pallet
kgs
400 kgs400
Spindle speed
rpm
6000 rpm6000
Spindle bore taper
type
BBT40 typeBBT40
Motor power (cont./S2 15 min S3 25%)
kW
18.5 / 15 kW18.5 / 15
Rapid traverse rate ( X / Y / Z )
mm
48/48/48 mm48/48/48
No. of tools
nos
40 nos40
Max. tool length
mm
300 mm300
Max. tool weight
kgs
8 kgs8
Front x Side x Height
mm
3200 x 5450 x 2935 mm3200 x 5450 x 2935
Weight
kgs
10000 kgs10000
Power
kW
18.5 / 15 kW 18.5 / 15
