LX20T L3
LX20T L3 is a volume-based CNC turning center designed for continuous production and consistent machining performance. With a 310 mm turning length, 320 mm turning diameter, and 8” chuck size, it is ideal for medium-sized components. Built for high productivity and reliability, the LX Series is well-suited for Automotive, Pump, Valve, Textile components, and General engineering.
Specifications
Description
Unit
Type
Swing over bed
mm
510 mm510
Max. Turning Diameter
mm
320 mm320
Max.Turning Length
mm
310 mm310
Admit between Centres
mm
440 mm440
Chuck Size
mm
210 mm210
Spindle nose
Type
A2-6 TypeA2-6
Hole through Spindle
mm
61 mm61
Max. Spindle speed
rpm
4000 rpm4000
Motor Power (cont. / Int)
kW
7.5 / 11 /15 kW7.5 / 11 /15
Inclination of Carriage
Deg
30° to Horizontal Plane Deg30° to Horizontal Plane
Cross Travel (X - Axis)
mm
185 mm185
Longitudinal Travel (Z- Axis)
mm
370 mm370
Rapid Traverse, X and Z Axes
m/min
30 / 30 m/min30 / 30
Number of Stations
Nos.
8 Nos.8
Tool Shank Size
mm
25 x 25 mm25 x 25
Turret Indexing
Type
Bi - directional TypeBi - directional
Turret Indexing Time
Sec
1 Sec1
Max. Boring Bar Diameter
mm
40 mm40
Quill Diameter
mm
75 mm75
Quill stroke
mm
100 mm100
Quill taper
type
MT-4 typeMT-4
Tailstock base stroke
mm
235 mm235
Controller
Type
Fanuc / Siemens TypeFanuc / Siemens
Front x Side x Height
mm
2065 x 1700 x 1852 mm2065 x 1700 x 1852
Weight
kg
3200 kg3200
