TURNMILL
LR30TM L7
LR30TM L7 is a Heavy Duty Turnmill Center designed for robust machining applications and consistent production performance. It offers a maximum turning length of 630 mm and a turning diameter of 400 mm, supported by a 12” chuck that ensures strong and stable workholding for larger components. Equipped with a powerful 18.5 / 15 kW spindle motor, the machine delivers excellent cutting capability for heavy-duty operations.
Specifications
Description
Unit
Type
Swing over bed
mm
680 mm680
Admit Between Centres
mm
820 mm820
Max. Turning Length
mm
630 mm630
Max. Turning Diameter
mm
400 mm400
Chuck Diameter
inch
12 inch12
Spindle nose
type
A2-8 typeA2-8
Hole through Spindle
mm
77 mm77
Max. Spindle speed
rpm
3500 rpm3500
Power
kW
18.5 / 15 kW18.5 / 15
Inclination of Carriage
deg
45° to Horizontal Plane deg45° to Horizontal Plane
Cross Travel (X - Axis)
mm
250 mm250
Longitudinal Travel (Z- Axis)
mm
710 mm710
Rapid Traverse, X and Z Axes
m/min
20/24 m/min20/24
Driven motor power
kW
4.5 kW4.5
Rotary tool speed
rpm
5000 rpm5000
Number of Stations
Nos.
12 Nos.12
Tool Shank Size
mm
25 x 25 mm25 x 25
Max. Boring Bar Diameter
mm
40 mm40
Turret Indexing
Type
Servo TypeServo
Turret Indexing Time
Sec
0.65 Sec0.65
Quill Diameter
mm
85 mm85
Quill Stroke
mm
80 mm80
Quill Taper
mm
MT-3 mmMT-3
Controller
Type
Fanuc TypeFanuc
Front x Side x Height
mm
3015 x 1615 x 2240 mm3015 x 1615 x 2240
Weight
kg
5200 kg5200
