TURNMILL
LR40TM L25
LR40TM L25 is a high-capacity Turnmill Center designed for machining large and complex components in demanding production environments. With a maximum turning length of 2320 mm and a turning diameter of 550 mm, it offers excellent capability for heavy-duty applications. Equipped with an A2-15 spindle nose, 533 mm chuck size, 12-station live tool turret, and 4000 rpm rotary tool speed, it enables efficient turning and milling operations in a single setup. Ideal for Oil & Gas, Railway, Defence, Aerospace, and Energy industries.
Specifications
Description
Unit
Type
Swing over bed
mm
745 mm745
Max. Turning Length
mm
2320 mm2320
Max. Turning Diameter
mm
550 mm550
Chuck Size
mm
533 mm533
Spindle nose
Type
A2-15 TypeA2-15
Hole Through Spindle
mm
181 mm181
Max. Spindle speed
rpm
1250 rpm1250
Motor Power (cont. / Int)
kW
18.5/22 kW18.5/22
Cross Travel (X - Axis)
mm
335 mm335
Longitudinal Travel (Z- Axis) Travel Z - Axis
mm
2490 mm2490
Rapid Traverse, X and Z Axes
m/min
24/10 m/min24/10
Number of Stations
Nos.
12 Nos.12
Tool Shank Size
mm
32 x 32 mm32 x 32
Max. Boring Bar Diameter
mm
60 mm60
Turret Indexing
Type
Bi-directional TypeBi-directional
Turret Indexing Time Time (per station)
Sec
<1 Sec<1
Rotary Tool Speed
rpm
4000 rpm4000
Rotary Tool Motor Power
kW
6.4 kW6.4
Quill Diameter
mm
120 mm120
Quill Stroke
mm
120 mm120
Quill Taper
Type
MT-6 TypeMT-6
CNC System
Type
Fanuc TypeFanuc
